5G / 4G / LTE wall-mounted antenna 4DBI / 698-960MHz 5.2DBI / 1710-2170MHz 4DBI / 2400-2700MHz 3DBI / 2800-3500MHz

From the supplier and OEM business from the wireless infrastructure to the wireless communication carrier, the full set of new antenna products have mainly included: the waterproof antenna used in harsh environments, using patch technology broadband antennas, and has a plate antenna of electric control inclination. High performance miniaturized antenna and broadband microwave devices in each system. The company has become an excellent supplier in the antenna industry, with a good reputation in the same industry.。

Contact information

Product Details

Electrical parameter

Frequency 698-960/1710-3500MHz

Bandwidth 262/990MHz

Gain 1 4DBI / 698-960MHz

Gain 2 5.2dbi / 1710-2170MHz,

Gain 3 4DBI / 2400-2700MHz

Gain 4 3DBI / 2800-3500MHz

Wave ratio ≤ 2.5

Radiation Omni-Direction

Polarization method vertical

Lightning protection DC-GROUNDED

Enter the maximum power 50W

Impedance 50?

Connect SMA MALE

Line type RG58

Feeding line length 3M

Product material ABS

Installation Wall Mount

Mechanical parameter

Antenna size φ48x82mm

Weight 208g

Work temperature -40 ℃ to 70 ℃
