| Standard regulation: 6N-18N | |
| Interchangeability: The same model product should be interchangeable | |
| Characteristic impedance: 50Ω | |
| Contact resistance (normal) internal / outer conductor ≤ 1MΩ | |
| Frequency range: DC-6000MHz | |
| Maximum allowable power: 250W / 300MHz, 160W / 3500MHz, 100W / 900MHz, 75W / 1.2GHz, 52W / 1.9GHz, 42W / 2.4GHz, 36W / 3GHz, 10W / 6GHz | |
| Nominal discharge voltage: 230 ± 20% | |
| Residual voltage \\u003c600KV / US | |
| Resident wave ratio ≤1.5 AT6G | |
| Insert loss \\u003c0.4db | |
| Shell Protection Level: IP67 |
| Specification specification | UHF connector | NR / NR type connector | NR / NP connector |
| Ca-23rs | Ca-23rp. | ||
| Frequency Range | DC~1000MHz | DC~2500MHz | DC~2500MHz |
| Resident waveby (VSVR) | Less than 1.1 | Less than 1.1 | Less than 1.1 |
| loss lose | Less than 0.2dB | Less than 0.2dB | Less than 0.2dB |
| Power | 400W PEP | 200W PEP | 400W PEP |
| Voltage at the time of discharge startup | DC 350V ± 15% | DC 230V ± 15% | DC 350V soil 15% |
| Shock wave emission voltage (1x40) US | 1,000V | 1,000V | 1,000V |
| Shock Wave Current (1x40) US | 6，000A | 6，000A | 6，000A |
| Impact wave repeated discharge (1x40) US500A, more than 500 times | DC 350V 20% | DC 230V ± 20% | DC 350V 20% |
| Insulation resistance DC100V | More than 10,000mΩ | More than 10,000mΩ | More than 10,000mΩ |
| Connector adapter | N-R/N-R | N-R/N-P | |
|
External dimensions (Maximum value includes. Connector) |
66W*41H*20Dmm | ||
| weight | 113g | 114g |
