Electrical performance parameters
Temperature range - 55 ~ + 165 ° C
Impedance 50 Ω
Frequency range DC ~ 6GHz
Working voltage 170V Max
Withstand voltage 500V RMS
Directional straight
Installation method PCB
Contact resistance
Center contact ≤ 5 m Ω
External contact ≤ 2.5 m Ω
Insulation resistance ≥ 1000 m Ω
Standing wave ratio ≤ 1.15
Durability (matching) ≥ 500 cycles
Materials and electroplating
Gold plated brass shell
Elastic contact beryllium plating
Inner conductor beryllium or tin brass gold plating
Insulator PTFE crimping suite copper alloy
Gold plated brass pin
