Electrical performance parameters

Temperature range - 65 ~ + 165 ° C

Impedance 50 Ω

Frequency range DC ~ 6GHz

Working voltage 250V (50 Ω)

Withstand voltage 750V (50 Ω)

Directional straight

Installation method PCB

Contact resistance

Center contact ≤ 5 m Ω

External contact ≤ 2.5 m Ω

Insulation resistance ≥ 1000 m Ω

Standing wave ratio ≤ 1.15

Durability (matching) ≥ 500 cycles

Materials and electroplating

Gold plated brass shell

Gold plated brass pin

Socket brass Gold Plated

Elastic contact beryllium plating

Insulator PTFE

Crimping kit copper alloy nickel plated or gold plated
